Roofline surveys
Measured from Google's building mask and surface model, drawn back onto the aerial, the 3D model and every street frame. No site visit.
6 properties · 0 with a lead
McKinney166 ft · 2-stMcKinney 2184 ft · 1-stHighland Park205 ft · 2-stUniversity Park90 ft · 2-stFrisco202 ft · 1-stPlano243 ft · 2-st
No leadNobody at 4400 Beverly Dr, Dallas, TX 75205 has asked for a quote in sandbox mode.
Dallas
4400 Beverly Dr, Dallas, TX 75205
4,608 sq ft footprint · 19 runs · 15 corners · aerial 2023-11 · street 2012-10
Lit roofline
205ft
eave + rake + hip
Front
32ft
street-facing
Corner drops
324ft
15 verticals
Ridge
35ft
two storeys
Pitch
35°
median measured
Classification unreliable on this roof. The split came out 3% eave / 96% rake, and a real house has more gutter than gable edge. The total is unaffected — it is eave + rake + hip, so mislabelling moves footage between columns without changing the sum. Quote from the total.
EaveRakeHipRidgeCorner drop
Line breakdown
Eave7 ft · 0 front
Rake196 ft · 32 front
Hip2 ft · 0 front
Ridge57 ft · 19 front
Corner drops324 ft over 15
Priced on 205 ft
Two-storey, +20% on the cardI already own lightsinstall-only, labour$1,046
I don't want to own lightslease, C9 supplied and stored$3,055
Up all yearpermanent track$5,740
After the 15% early-booking discount on seasonal work. January takedown is in every seasonal price.
Every run on this roof (19)
| # | Feet | Pitch | Eave ft | Type | Elevation |
|---|---|---|---|---|---|
| 1 | 56.1 | 21° | 26.0 | rake | rear |
| 2 | 31.8 | 37° | 24.5 | rake | side |
| 3 | 25.0 | 35° | 25.2 | rake | side |
| 4 | 23.4 | 0° | 13.4 | flat | side |
| 5 | 22.5 | 27° | 24.4 | ridge | rear |
| 6 | 20.4 | 37° | 20.9 | rake | side |
| 7 | 16.7 | 35° | 26.2 | rake | front |
| 8 | 16.4 | 47° | 23.3 | ridge | side |
| 9 | 13.5 | 17° | 33.4 | ridge | front |
| 10 | 12.2 | 33° | 25.2 | rake | front |
| 11 | 9.6 | 45° | 14.0 | rake | side |
| 12 | 7.7 | 21° | 16.0 | rake | rear |
| 13 | 7.3 | 35° | 26.4 | rake | side |
| 14 | 7.2 | 46° | 18.7 | eave | side |
| 15 | 6.3 | 23° | 15.1 | rake | rear |
| 16 | 3.3 | 41° | 24.4 | rake | front |
| 17 | 2.9 | 45° | 24.1 | ridge | front |
| 18 | 2.3 | 51° | 13.9 | hip | side |
| 19 | 2.1 | 23° | 28.4 | ridge | front |
All six, side by side
| Property | Lead | Sq ft | Lit | Front | Corners | Pitch | Ridge | Install-only |
|---|---|---|---|---|---|---|---|---|
| McKinney1209 Shady Oaks Cir, McKinney, TX 75072 | — | 3,550 | 166 | 53 | 243 | 33° | 27 | $1,015 |
| McKinney 21701 Coventry Ln, McKinney, TX 75069 | — | 1,683 | 184 | 52 | 107 | 24° | 18 | $846 |
| Highland Park4400 Beverly Dr, Dallas, TX 75205 | — | 4,608 | 205 | 32 | 324 | 35° | 35 | $1,046 |
| University Park3400 Amherst Ave, Dallas, TX 75225 | — | 2,366 | 90 | 13 | 146 | 35° | 26 | $1,015 |
| Frisco5200 Bluewater Dr, Frisco, TX 75036 | — | 2,589 | 202 | 0 | 28 | 26° | 18 | $859 |
| Plano5600 Preston Meadow Dr, Plano, TX 75024 | — | 2,636 | 243 | 126 | 186 | 28° | 25 | $1,239 |
Every figure is measured from imagery, not surveyed on site. The total lit line is reliable; the eave/rake/hip split is a hint for the installer and is flagged where it looks wrong.
